Components
|
Parameters
|
|
Solar Module
|
Pmax(W)
|
30-320W solar panel
|
|
Vmp (V)
|
18V or 35.5V
|
|
Imp (A)
|
From 1.67A to 9A
|
|
Light Fixture
|
Material
|
Aluminum die casting & Toughened glass
|
|
Operating Temperature
|
-40°C~75°C
|
|
Protection Level
|
IP65 rate for led solar street light
|
|
LED Light Source
|
LED Chip
|
BRIDGELUX or Cree
|
|
Color Temperature
|
3800-6500K(warm white/pure white)
|
|
Luminous flux
|
5300 LM led solar street light
|
|
Operating temperature
|
-40°C~75°C
|
|
Current Source
|
DC 12V/24V
|
|
Power
|
15W/18W/21W/24W/30W/36W/42W/48W/54W/60W/80W
|
|
Lighting Pole
|
Height
|
3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m
|
|
Material
|
Q235/345/GR60
|
|
Surface Treatment
|
Hot-dip galvanizing, Static spray for led solar street light
|
|
Size
|
φ60-φ200,δ3-5m, vary according to models
|
|
Flange Plate
|
300*300*16, vary according to models
|
|
Battery
|
Capacity
|
200AH (100AH*2pcs)
|
|
Type
|
Gel/AGM Battery
|
|
Dimension
|
546*1203*30
|
|
Weight
|
28Kg, varying with different led solar street lights
|
|
Controller
|
Rated voltage and current
|
12V/10A or 24V/10A waterproof
|
|
Weight
|
0.165Kg
|
|
Two times rainy day backup
&Protective Function
|
Two times of rainy day backup.
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.
|
|
Accessories
|
Cable
|
2.5 mm2, 15m
|
|
Battery Box
|
200AH ABS battery box or metal box with hot-dip galvanizing spray treatment
|
|
Foundation Kit
|
Dismountable foundation kit, saving in shipping
|
